MPPT 60A Solar Battery Charge Controller LCD 12V 24V Auto with USB 5V 1500mA Solar Regulator High Efficiency Solar Tracking System
This is a three-time controller into the evening(evening)working time,an interval of rest or pause time,Dawn working time(morning light function),the user can according to their needs,set a different time.
A:time(evening working)B:time(Pause working)C:time(dawn working)
This is a compatible MPPT charge controller PWM intelligent/efficient/energy saving,he not only has efficient MPPT controller charging function to automatically track the maximum power point,10%-30% higher than the ordinary controller chargingefficiency,also has standby energy saving,more than 30% energy than ordinary controller,the standby power consumption of only 10mA-15mA.
Note:It is high qualitycompatible MPPT + PWM Solar Controllers ,not 100% Ture MPPT
1.Product introduction:
“T”series of an intelligent,multi-purpose solar charge controller
|
LCD Screen display |
Battery reverse discharge protection |
|
Simple(and more time control) operation |
Battery reverse polarity protection |
|
PWM charing mode+MPPT |
Battery under voltage protection |
|
Parameter user can reset |
Overload,short-circuit protection |
|
A key to open and close the load |
Automatic Temperature compensation function |
|
A key to restore the factory setting |
USB 5V charge(current 1500mA/1.5A)Optional |
2.Packing Including
1pcs 60A Solar Controller MPPT L60
1pcs Temperature Sensor
1pcs English User Manual
3.LCD Operating interface description :
4.Parameter table:
|
Parameters/Model |
MPPT T-10 |
MPPT T-20 |
MPPT T-30 |
MPPT T-40 |
MPPT T-60 |
MPPT T-80 |
|
Maximum Power Current |
12A |
20A |
30A |
40A |
60A |
80A |
|
Installation Lin(mm2) |
4mm2 |
8mm2 |
10mm2 |
12mm2 |
16mm2 |
20mm2 |
|
Installaton Line(AWG) |
10#(AWG) |
8#(AWG) |
7#(AWG) |
6#(AWG) |
4#(AWG) |
2#(AWG) |
|
Weight |
280g |
300g |
475g |
500g |
800g |
900g |
|
Peak power of solar cell panel (Max Wp) |
130W |
260W |
380W |
500W |
800W |
1000W |
|
Battery capacity configuration |
100AH |
200AH |
300AH |
400AH |
600AH |
800AH |
|
Dimensions |
143*89*46(mm) |
187*97*61(mm) |
188*128*61(mm) |
|||
|
Battery float voltage |
13.8V(12V system)/27.6V(24V system) |
|||||
|
Battery (under voltage) protection |
10.6V(12V system)/21.2V(24V system) |
|||||
|
Battery(under voltage)recovery voltage |
12.6V(12V system)/25.2V(24V system) |
|||||
|
System load loss:<=13mA |
Loop Buck;<=100mV |
|||||
|
Operation Temperature :-10degC~60degC |
Storage Temperature :-30degC~-70degC |
|||||
|
Operation Temperature :<=90%,No condensation |
Temperature compensation :-4mV/Cell/degC |
|||||
|
Maximum open circuit voltage of the solar panel |
18V~24V(12V system) 36V~48V(24V system) |
|||||
|
Solar Panel maximum open circuit voltage |
<=48V |
|||||
|
Link |
||||||
5.Installation
1.Ready Qi installation tools and materials,and cable.Please matching suitable cable
2.Ensure that the current desity<4A/mm2 That will help reduce the line pressure drop.check the installation site meets the relevant safety requirements,avoid damp,dusty,flammable,explosive and corrosive gases
3.Install the controller fixed to the vertical plane,see Section V mounting aperture and hole spacing.In order to ensure a good controller cooling conditions,the controller on the bottom of each reserved 10cm space
4.As shown on the right wiring sequense:load,battery,solar Battery plate is connected to the controller to be taken to ensure that the load,battery,The polarity of the solar cell panel and controller
5. Before use:external temperature sensor probe into the left of the controller temperature probe interface probe placed in similar battery temperature.(Line extensive must be build-in devices of the external temperature probe coextensive Otherwise,the controller will control parameters of the temperature compensation of the error
6.Warning:In order to prevent accidents from occurring,install:non-professionals can not be engaged in loading and unloading operations
6.Charging Problem Solution:
-
No proper installation of solar panels cable polarity(ldquo+rdquordquo-rdquo) Removing the polarity,you can re-install the correct
-
More than the rated power of solar panels to reduce solar panel power does not exceed the rated power controller discharge Problem Solution
-
Removing the load is not properly connected to the load,re-install the correct
-
More than the rated load power to reduce load power,the controller does not exceed the rated power
-
Instantaneous starting current is too large,the battery capacity is too small,the replacement of high-capacity batteries,button troubleshooting
-
Wire Cable polarity loose or too square and increase retightening bold cable
-
All keys can troubleshoot faults,press 5 seconds to restore factory settings.
7.Pictures:
